System monitorowania stanu LifeCheck dla ograniczników BLITZDUCTORconnect
:quality(98)/www.dehn.pl/store/f/16541169/HDVORSCHAU/910710a2_16-9.jpg)
:quality(98)/www.dehn.pl/store/f/16541169/HDVORSCHAU/910710a2_16-9.jpg)
- Minimum wiring effort thanks to combined transmitter/receiver unit
- Quick and comfortable initial operation
- Visual reverse unit for terminating a monitoring group
- Simple line connection thanks to push-in connection technology
- Condition monitoring of arresters of the BLITZDUCTORconnect series
- Simple visual monitoring principle
- Resistant to extraneous light
- Integrated group display and remote signalling contact (break contact)
- Quick and easy initial operation
Details
:quality(98)/www.dehn.pl/store/f/16541173/HDVORSCHAU/910710a2_Detail_4.jpg)
Approval for use in hazardous areas
:quality(98)/www.dehn.pl/store/f/16541173/HDVORSCHAU/910710a2_Detail_4.jpg)
:quality(98)/www.dehn.pl/store/f/16541171/HDVORSCHAU/910710a3_Detail_2.jpg)
Simple installation / initial operation with combined transmitter/receiver unit
:quality(98)/www.dehn.pl/store/f/16541171/HDVORSCHAU/910710a3_Detail_2.jpg)
:quality(98)/www.dehn.pl/store/f/16541172/HDVORSCHAU/910711d_Detail_3.jpg)
Remote signalling of the status of arrester groups (break contact)
:quality(98)/www.dehn.pl/store/f/16541172/HDVORSCHAU/910711d_Detail_3.jpg)
:quality(98)/www.dehn.pl/store/f/16541170/HDVORSCHAU/927224a2_Detail_1a.jpg)
Status indication (group display) for simple and quick maintenance
:quality(98)/www.dehn.pl/store/f/16541170/HDVORSCHAU/927224a2_Detail_1a.jpg)
DRC IRCM
Condition monitoring unit DEHNrecord, set for DIN rail mounted devices with integrated visual transmitter/receiver and visual deflection unit for monitoring the condition of BCO arresters with LifeCheck. Visual status indication via LED group display in combination with remote signalling contact (break contact).
1 Produkt
Nr kat. 910710 DRC IRCM
GTIN / EAN 4013364424678, Nr taryfy celnej: 90308900, Waga brutto: 68.45 g, Jednostka opakowaniowa: 1.00 szt.
Dane techniczne
Zakres napięcia wejściowego (DC) (UIN ) | 6-35 V DC |
Maksymalny znamionowy pobór prądu (IIN ) | ≤ 10 mA |
Zakres temperatury pracy (TU ) | -30°C ... +70°C |
Certyfikaty | UL |
